Part Number

Conductor

Nominal O.D.

Approx weight

F1800

F1803

F1804

F1805

F2659

F2660

F2661

F2637

F2638

2
3
4
5
6
8
10
12
15

0.12
0.128
0.137
0.15
0.163
0.176
0.216
0.223
0.246

10
13
15
18
21
27
34
40
48

F1800	2	.120	10
F1803	3	.128	13
F1804	4	.137	15
F1805	5	.150	18
F2659	6	.163	21
F2660	8	.176	27
F2661	10	.216	34
F2637	12	.223	40
F2638	15	.246	48

Riser Rated 20 Awg - 7/28 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F1822	2	.138	13
F1823	3	.149	17
F1824	4	.160	22
F1825	5	.175	27
F1827	12	.261	59
F1828	15	.300	74
F1829	20	.375	114

Riser Rated 18 Awg - 7/26 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F1830	2	.162	18
F1833	3	.172	25
F1834	4	.188	32
F1835	5	.217	40
F2693	6	.236	53
F2694	8	.253	59
F1839	9	.275	67
F2695	10	.310	77
F2696	12	.315	87
F2697	15	.359	126

Riser Rated 16 Awg - 7/24 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F1842	2	.190	30
F1843	3	.231	50
F1844	4	.223	51

Riser Rated 14 Awg - 19/27 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F1852	2	.238	47
F1854	4	.269	60

Riser Rated 12 Awg - 19/25 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F1862

2

.286

70
