Part Number

Conductor

Nominal O.D.

Approx weight

F9301	2	.120	9
F9327	3	.134	12
F9302	4	.138	15
F9303	6	.165	21
F9304	8	.179	27
F9305	10	.210	33
F9322	12	.217	39

Plenum Rated 20 Awg - 10/30 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F9306	2	.134	12
F9307	3	.140	16
F9308	4	.156	21

Plenum Rated 18 Awg - 7/26 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F9309	2	.158	17
F9310	3	.168	24
F9311	4	.184	31
F9312	6	.222	44
F9313	8	.242	57
F9320	10	.292	73
F9332	12	.271	80

Plenum Rated 16 Awg - 19/25 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F9314	2	.182	24
F9315	4	.212	44

Plenum Rated 14 Awg - 19/25 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F9316	2	.216	36
F9329	4	.250	71

Plenum Rated 12 Awg - 19/25 Stranded

Part Number

Conductor

Nominal O.D.

Approx weight

F9330	2	.258	62
F9331	4	.285	85
